Bend 90° (Steel)

Our standard tubing system is of zinc coated carbon steel tubing and is used at 90 % of all Dustcontrol installations. Heavy wall thickness results in long life even in installations where considerable abrasion is present.

Select model

Description

Dustcontrol pipes are zinc coated carbon steel. The material density gives the pipes a long life.

Note: The letters in the table header refer to the drawing.

**Bend 90°**
Part No	Description	d [mm]	r [mm]	b [mm]	h [mm]	t [mm]	Weight [kg]
3310	Ø50	50.8	120	75	220	1.5	0.6
3309	Ø50	50.8	85	75	185	1.5	0.3
3117	Ø50	50.8	50	–	115	1.5	0.3
3118	Ø76	76	65	–	150	1.5	0.6
3311	Ø76	76	160	180	313	1.5	1.3
3005	Ø76	76	175	–	213	2.9	1.45
3319	Ø108	108	160	165	380	2.0	3.0
3061	Ø159	159	375	–	455	4.5	10.1
